Technische Daten - Dosenverschliesser Getränke
ferruCOMPACT <60'000cph
ferruBASIC <60'000cph
ferruBASIC >60'000cph
SmartCan
Technische Daten ferruCompact FC03 / FC06 / FC08
| FC03 | FC06 | FC08 | |
|---|---|---|---|
| Falzstationen | 3 | 6 | 8 |
| Leistung | 80-355 D/min || 4'800-21'300 D/h | 130-750 D/min | 7'800-45'000 D/h | 330-1'000 D/min | 19'800-60'000 D/h |
| Dosendurchmesser | 50-73 mm || 200-300 imp | 50-99 mm | 200-314 imp | 50-73 mm | 200-300 imp |
| Dosenhöhe | 87-220 mm || 3.425-8.661 in | 87-250 mm | 3.425-9.843 in | 87-250 mm | 3.425-9.843 in |
| Gewicht | 1'800 kg || 4'000 lbs | 2'500 kg | 5'500 lbs | 2'600 kg | 5'723 lbs |
Technische Daten ferruBasic F05 / F06 / F08
| F05 | F06 | F08 | |
|---|---|---|---|
| Falzstationen | 5 | 6 | 8 |
| Leistung | 210-625 D/min || 12'600-37'500 D/h | 250-750 D/min || 15'000-45'000 D/h | 330-1'000 D/min || 19'800-60'000 D/h |
| Dosendurchmesser | 50-84 mm || 200-305 imp | 50-84 mm || 200-305 imp | 50-73 mm || 200-300 imp |
| Dosenhöhe | 88-212 mm || 3.465-8.346 in | 88-212 mm || 3.465-8.346 in | 88-212 mm || 3.465-8.346 in |
| Gewicht | 2'800 kg || 6'200 lbs | 3'200 kg || 7'100 lbs | 3'400 kg || 7'500 lbs |
Technische Daten ferruBasic F12-1 / F12-2 / F18
| F12-1 / F12-1 HD | F12-2 / F12-2 HD | F18 | |
|---|---|---|---|
| Falzstationen | 12 | 12 | 18 |
| Leistung | 580-1'600 D/min || 34'800-96'000 D/h | 580-1'750 D/min || 34'800-105'000 D/h | 850-2'500 D/min || 51'000-150'000 D/h |
| Dosendurchmesser | 50-73 mm || 200-300 imp | 50-73 mm || 200-300 imp | 50-73 mm || 200-300 imp |
| Dosenhöhe | 88-212 mm || 3.465-8.346 in | 88-212 mm || 3.465-8.346 in | 88-196 mm (F18N) || 3.465 - 7.717 in (F18N) |
| Gewicht | 5'250 kg || 11'575 lbs | 5'400 kg || 11'905 lbs | 7'000 kg || 15'500 lbs |
Technische Daten FS14-1 / FS14-2 / FS18 SmartCan by KHS/Ferrum
| FS14-1 | FS14-2 | FS18 | |
|---|---|---|---|
| Falzstationen | 14 | 14 | 18 |
| Leistung | 1'600 D/min || 96'000 D/h | 1'800 D/min || 108'000 D/h | 2'266 D/min || 136'000 D/h |
| Dosendurchmesser | 50-73 mm || 200-300 imp | 50-73 mm || 200-300 imp | 50-73 mm || 200-300 imp |
| Dosenhöhe | 87-200 mm || 3.425-7.874 in | 87-200 mm || 3.425-7.874 in | 87-220 mm || 3.425-8.661 in |
| Gewicht | 3'350 kg || 7'385 lbs | 3'500 kg || 7'716 lbs | 6'500 kg || 14'330 lbs |
